Encoder Readout - Data Sheets

E-MUX005

For Incremental Encoders

·         ECM 514 A  update Rev 5, 2015
 - Trigger Function for Time-Stamping
 - Ultra precise Home-Switch position finding
 - Preserve Counter-contents and with it Home-Position at VME-resets (booting)



·         ECM504, ECM 504 A (For new designs use ECM514A)



E-MUX005/24

For Absolut Encoders

ECM 505/F 24V Encoder update 2008

ECM 505/F 5V Encoder update 2012

SSI550

For Absolut Encoders

ECM901 new, 2015
 - Replacement for SLS-Girder-Mover- or Scraper-Encoder readout



For Absolut Encoders with BISS-C Interface





ECM504B/F BISS-C

ECM505/24 , ECM505/36  ( For 0..32 bit Encoders use ECM 505/F )
